Model
Bosch SGI43A25GB/14
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
SGI43A25GB/14
1 diagram112 parts
Parts Sections (1)
Diagram
Door & Housing, Seals & Gaskets (0104-8100)
Parts in Door & Housing, Seals & Gaskets (0104-8100)
115 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0104 |  | Lock | $70.95 ApplianceParts Pro |
| 0106 |  | Rod | - |
| 0108 |  | 00165242NLA Switch | Discontinued |
| 0118 |  | Cover | $10.88 Part Advantage |
| 0199 |  | Cable harness | - |
| 0200 |  | Door-inner | - |
| 0201 |  | Wood Screw | $2.51 Part Advantage |
| 0202 |  | Screw | $6.70 Part Advantage |
| 0206 |  | Door Seal | $55.48 Part Advantage |
| 0210 |  | 00490467NLA Dispenser | Discontinued |
| 0211 |  | Adjusting device | - |
| 0212 |  | Lid | $7.96 Part Advantage |
| 0213 |  | Sealing | $8.37 Part Advantage |
| 0214 |  | Lever, Wrap, Seal | $11.72 Part Advantage |
| 0215 |  | Plunger | - |
| 0216 |  | Detergent Lid | $39.34 Part Advantage |
| 0217 |  | Sealing | $12.20 Parts Dr |
| 0218 |  | Repair-set | $9.63 Part Advantage |
| 0219 |  | Repair-set | - |
| 0220 |  | Actuator | $21.56 Parts Dr |
| 0221 |  | Switch | $20.93 Part Advantage |
| 0234 |  | Insulating part | - |
| 0240 |  | Mounting Set for Dishwashers | $28.09 ApplianceParts Pro |
| 0242 |  | Strip | - |
| 0244 |  | Strip | - |
| 0246 |  | Holder | $5.45 Part Advantage |
| 0302 | | Panel side | - |
| 0304 | | Panel side | - |
| 0306 |  | Holder | $18.43 ApplianceParts Pro |
| 0308 |  | Holder | $20.57 ApplianceParts Pro |
| 0310 |  | Hook | - |
| 0314 |  | Rack guide rail | $38.03 PartSelect |
| 0318 |  | Front/Rear End Cap Set | $9.63 Part Advantage |
| 0320 |  | Rail | - |
| 0322 |  | Strip | - |
| 0324 |  | Strip | - |
| 0326 |  | Strip | - |
| 0328 |  | Insulating part | - |
| 0330 | | Insulating plate | - |
| 0332 |  | Steam Safety Sheet | - |
| 0333 |  | Attachment Brackets | $12.41 Part Advantage |
| 0334 |  | Repair set-role | $63.01 Parts Dr |
| 0350 |  | Cover | - |
| 0352 |  | Sealing | - |
| 0354 |  | Cover | - |
| 0356 |  | Hose-vent | - |
| 0401 |  | Sealing | $8.79 Part Advantage |
| 0402 |  | Sealing | $8.79 Part Advantage |
| 0404 |  | Cover | - |
| 0405 |  | Switch | - |
| 0411 |  | Capacitor | - |
| 0412 |  | Suspension | $2.88 RepairClinic |
| 0413 |  | Pump-housing | - |
| 0415 |  | Case-upper part | - |
| 0416 |  | Sealing | $22.19 Part Advantage |
| 0417 |  | Hose clamp | $17.16 Part Advantage |
| 0420 |  | Water softener | - |
| 0423 |  | Sealing | - |
| 0425 |  | Valve-regeneration | $39.95 ApplianceParts Pro |
| 0428 |  | Cover | - |
| 0429 |  | Screw | $1.67 Part Advantage |
| 0430 | | Sump | - |
| 0431 |  | Sealing | $27.04 Parts Dr |
| 0432 |  | Holder | - |
| 0433 |  | Valve-non return | $7.53 Part Advantage |
| 0434 |  | Cover | $10.95 ApplianceParts Pro |
| 0435 |  | Pump-drain | $99.25 ApplianceParts Pro |
| 0436 |  | Hose | $14.83 RepairClinic |
| 0437 |  | O-Ring | $9.21 Part Advantage |
| 0438 |  | Sump Drain Hose | $10.47 Part Advantage |
| 0440 |  | Hose connection inlet | $5.83 Parts Dr |
| 0444 |  | Cover | $15.36 ApplianceParts Pro |
| 0446 |  | Regulator-water level | - |
| 0448 |  | Switch | $20.51 Part Advantage |
| 0452 |  | Funnel | $10.66 ApplianceParts Pro |
| 0501 |  | Screw-adjust | $2.88 RepairClinic |
| 0502 |  | Foot | $14.59 Parts Dr |
| 0506 |  | Roller-tension | - |
| 0508 |  | Hinge Bushing | $10.88 Part Advantage |
| 0510 | | Hinge Bushing | $10.88 Part Advantage |
| 0516 |  | Hinge | $49.45 ApplianceParts Pro |
| 0518 |  | Hinge | $45.10 Parts Dr |
| 0520 |  | Hinge | $43.11 Part Advantage |
| 0522 |  | Hinge | $41.85 Part Advantage |
| 0524 |  | Plate | - |
| 0526 |  | Plate | - |
| 0528 |  | Hood | - |
| 0530 |  | Float | $5.45 Part Advantage |
| 0532 |  | Lever | $4.73 RepairClinic |
| 0534 |  | Tube | $8.89 RepairClinic |
| 0540 |  | Capacitor-interference suppre. | - |
| 0554 |  | Stress-relief | - |
| 0556 | | Hose connection inlet | $5.83 Parts Dr |
| 0558 |  | Holder | $14.40 ApplianceParts Pro |
| 0562 |  | Valve-aquastop | - |
| 0564 |  | Cable connector | - |
| 0566 |  | Sealing | $27.79 ApplianceParts Pro |
| 0582 |  | Fixing kit | $15.95 ApplianceParts Pro |
| 0584 |  | Axis | $7.68 PartSelect |
| 0586 |  | Bushing | - |
| 0588 |  | Foot | - |
| 0600 |  | Tube | - |
| 0604 |  | Spray arm | - |
| 0606 |  | 00353507NLA Filter-fine | Discontinued |
| 0608 |  | Filter-micro | $51.73 Part Advantage |
| 0614 |  | Knife Rack | - |
| 0616 |  | 00093044NLA Cup rack | Discontinued |
| 0618 |  | Strip | $13.86 ApplianceParts Pro |
| 0626 |  | Flip tine | - |
| 0628 |  | Clamp, Flip Tine | $9.21 Part Advantage |
| 0630 |  | Holder | $13.64 Parts Dr |
| 0640 |  | Cutlery Basket | $38.50 Part Advantage |
| 0644 |  | Tall/Large Item Sprinkler Head | $15.93 RepairClinic |
| 3020 |  | Micro-Filter | $11.95 ApplianceParts Pro |
| 8100 | | Micro-Filter | $11.95 ApplianceParts Pro |
