Model
Bosch SGV57T03GB/07
Dishwasher
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
SGV57T03GB/07Dishwasher
1 diagram119 parts
Parts Sections (1)
Diagram
Baskets & Wheels, Switches (0102-8100)
Parts in Baskets & Wheels, Switches (0102-8100)
124 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0102 |  | Plug | - |
| 0110 |  | Frame | $31.13 Parts Dr |
| 0111 |  | Ball Bearing Door Latch | $48.55 Part Advantage |
| 0112 |  | Switch | - |
| 0113 |  | On/Off Main Switch | $48.55 Part Advantage |
| 0123 |  | 00603630NLA Push button set | Discontinued |
| 0199 |  | Cable harness | - |
| 0200 |  | Dispenser | - |
| 0201 |  | Sealing | $12.20 Parts Dr |
| 0202 |  | 00182136NLA Lid | Discontinued |
| 0203 |  | Rectifier | $34.90 PartSelect |
| 0204 |  | Switch | - |
| 0240 |  | Door-inner | - |
| 0241 |  | Screw | $6.70 Part Advantage |
| 0242 |  | Door Seal | $55.48 Part Advantage |
| 0250 | | Insulating part | - |
| 0260 | | Door-outer | - |
| 0261 |  | Strip | - |
| 0262 |  | Strip | - |
| 0290 |  | Mounting Set for Dishwashers | $28.09 ApplianceParts Pro |
| 0291 |  | Holder | $5.45 Part Advantage |
| 0293 |  | Plug | - |
| 0302 | | Panel side | - |
| 0304 | | Panel side | - |
| 0310 |  | Insulating part | - |
| 0312 |  | Strip | - |
| 0313 |  | Strip | - |
| 0314 |  | Strip | - |
| 0330 |  | Rail | - |
| 0331 |  | Seal | $65.83 Part Advantage |
| 0332 |  | Hook | - |
| 0333 |  | Holder | $20.57 ApplianceParts Pro |
| 0334 |  | Holder | $18.43 ApplianceParts Pro |
| 0335 | | Rail | - |
| 0336 |  | Front/Rear End Cap Set | $9.63 Part Advantage |
| 0337 |  | Rack guide rail | $38.03 PartSelect |
| 0350 |  | Cover | - |
| 0351 |  | Sealing | - |
| 0352 |  | Cover | - |
| 0353 |  | Hose-vent | - |
| 0390 |  | Steam Safety Sheet | - |
| 0391 |  | Attachment Brackets | $12.41 Part Advantage |
| 0392 |  | Repair set-role | $63.01 Parts Dr |
| 0402 |  | O-Ring | $9.21 Part Advantage |
| 0403 |  | Fixture | - |
| 0404 |  | Sump Drain Hose | $10.47 Part Advantage |
| 0405 | | O-Ring | $9.21 Part Advantage |
| 0412 |  | Switch | $20.51 Part Advantage |
| 0414 | | O-Ring | $9.21 Part Advantage |
| 0415 |  | Hose | $14.83 RepairClinic |
| 0423 |  | Sealing | - |
| 0428 |  | Valve-regeneration | $39.95 ApplianceParts Pro |
| 0429 |  | Valve-outlet | - |
| 0430 |  | Sump | $77.40 Parts Dr |
| 0431 |  | Sealing | $27.08 Parts Dr |
| 0432 |  | Holder | - |
| 0433 |  | Screw | $1.67 Part Advantage |
| 0434 |  | Cover | - |
| 0441 |  | Hose clamp | $17.16 Part Advantage |
| 0442 |  | Switch | - |
| 0443 |  | Cover | - |
| 0444 |  | Sensor-NTC | $54.05 Parts Dr |
| 0445 |  | Sealing | $8.79 Part Advantage |
| 0446 |  | Sealing | $8.79 Part Advantage |
| 0447 |  | Aqua Sensor | $50.51 Parts Dr |
| 0448 |  | Sealing | $9.21 Part Advantage |
| 0452 |  | 00167235NLA Capacitor | Discontinued |
| 0454 |  | Suspension | $2.88 RepairClinic |
| 0455 |  | Pump-housing | - |
| 0457 |  | Case-upper part | - |
| 0458 |  | Sealing | $22.19 Part Advantage |
| 0460 |  | Pump-drain | $99.25 ApplianceParts Pro |
| 0461 |  | Valve-non return | $7.53 Part Advantage |
| 0462 |  | Cover | $10.95 ApplianceParts Pro |
| 0463 | | Screw | $1.67 Part Advantage |
| 0490 |  | Funnel | $10.66 ApplianceParts Pro |
| 0501 |  | Sealing | $27.79 ApplianceParts Pro |
| 0502 |  | Valve-aquastop | - |
| 0503 |  | Cable connector | - |
| 0510 |  | Drain Hose | $23.02 Part Advantage |
| 0511 |  | Stress-relief | - |
| 0512 |  | Adapter | $12.98 Part Advantage |
| 0521 |  | Foot | $14.59 Parts Dr |
| 0523 |  | Hood | - |
| 0524 |  | Float | $5.45 Part Advantage |
| 0525 |  | Lever | $4.73 RepairClinic |
| 0526 |  | Tube | $8.89 RepairClinic |
| 0530 |  | Foot | - |
| 0531 |  | Bushing | - |
| 0532 |  | Axis | $7.68 PartSelect |
| 0540 |  | Capacitor-interference suppre. | - |
| 0550 |  | Hinge | $41.85 Part Advantage |
| 0551 |  | Roller-tension | - |
| 0552 |  | Hinge Bushing | $10.88 Part Advantage |
| 0553 |  | Hinge | $45.10 Parts Dr |
| 0554 |  | Plate | - |
| 0560 |  | Hinge | $43.11 Part Advantage |
| 0561 | | Roller-tension | - |
| 0562 | | Hinge Bushing | $10.88 Part Advantage |
| 0563 |  | Hinge | $49.45 ApplianceParts Pro |
| 0564 |  | Plate | - |
| 0566 |  | LED-announcement | $48.71 Parts Dr |
| 0590 |  | Fixing kit | $15.95 ApplianceParts Pro |
| 0591 |  | Screw-adjust | $2.88 RepairClinic |
| 0600 |  | Tube | - |
| 0601 |  | Upper Spray Arm Assembly | $53.41 Part Advantage |
| 0602 |  | Spray arm | - |
| 0603 |  | Tall/Large Item Sprinkler Head | $15.93 RepairClinic |
| 0610 |  | Filter-fine | - |
| 0611 |  | Filter-micro | $51.73 Part Advantage |
| 0620 |  | Lower crockery basket | $186.47 Part Advantage |
| 0621 |  | Dishwasher Rack Wheel | $6.30 Part Advantage |
| 0630 |  | Flip tine | - |
| 0631 |  | Bearing plate | $24.70 Part Advantage |
| 0632 |  | Cup rack | $16.32 ApplianceParts Pro |
| 0640 |  | Upper crockery basket | - |
| 0640 |  | Rack Height Adjustment Set | - |
| 0644 |  | Flip tine | - |
| 0645 |  | Flip tine | - |
| 0646 |  | Bearing plate | - |
| 0647 |  | 00093044NLA Cup rack | Discontinued |
| 0648 |  | Knife Rack | - |
| 0660 |  | Cutlery Basket | $50.79 Parts Dr |
| 8100 |  | Micro-Filter | $11.95 ApplianceParts Pro |
