Model
Bosch WFK6410GB/01
Washer
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WFK6410GB/01Washer
1 diagram36 parts
Parts Sections (1)
Diagram
Flaps & Holders, Hoses (0037-0145)
Parts in Flaps & Holders, Hoses (0037-0145)
36 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0037 |  | Holder | - |
| 0038 |  | Holder | $6.27 Parts Dr |
| 0039 | | Holder | - |
| 0040 | | 00029856NLA Clip-earth | Discontinued |
| 0041 | | Holder | - |
| 0047 |  | Foot | - |
| 0049 |  | Electric lock | - |
| 0053 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0055 |  | Window | $63.71 ApplianceParts Pro |
| 0060 | | 00474870NLA Case-rear part | Discontinued |
| 0061 |  | Worktop | - |
| 0088 |  | 00029863NLA Spring guide | Discontinued |
| 0090 | | Holder | - |
| 0093 | | Screw | - |
| 0094 | | Spring guide | - |
| 0095 |  | Spring-tank | - |
| 0096 |  | Spring-tank | $27.78 RepairClinic |
| 0097 |  | Shaft seal | $54.68 PartSelect |
| 0098 | | Fixing kit | - |
| 0099 | | Screw | - |
| 0100 |  | Bearing set | - |
| 0103 |  | Shock absorber | $44.85 RepairClinic |
| 0104 |  | Pulley | $81.95 PartSelect |
| 0105 |  | Sealing | $43.34 ApplianceParts Pro |
| 0106 | | Lock-clamp | - |
| 0113 | | Front | - |
| 0114 | | Weight | - |
| 0120 | | 00029867NLA Sealing | Discontinued |
| 0124 | | Sealing | - |
| 0125 |  | fastening ring | - |
| 0127 | | Hose connection inlet | - |
| 0131 |  | Ball-sump | - |
| 0132 | | 00056774NLA Sealing | Discontinued |
| 0136 |  | Holder | $14.40 ApplianceParts Pro |
| 0144 | | Latch | - |
| 0145 |  | Drain Hose | - |
