Model
Bosch WFK7410GB/01
Washer
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WFK7410GB/01Washer
1 diagram37 parts
Parts Sections (1)
Diagram
Flaps & Holders, Hoses (0037-0146)
Parts in Flaps & Holders, Hoses (0037-0146)
37 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0037 |  | Holder | - |
| 0038 |  | Holder | $6.27 Parts Dr |
| 0039 | | Holder | - |
| 0040 | | 00029856NLA Clip-earth | Discontinued |
| 0041 | | Holder | - |
| 0047 |  | Foot | - |
| 0049 |  | Electric lock | - |
| 0053 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0055 |  | Window | $63.71 ApplianceParts Pro |
| 0060 | | 00474870NLA Case-rear part | Discontinued |
| 0061 |  | Worktop | - |
| 0089 |  | 00029863NLA Spring guide | Discontinued |
| 0091 | | Holder | - |
| 0094 | | Screw | - |
| 0095 |  | Screw | - |
| 0096 | | Spring guide | - |
| 0097 |  | Spring-tank | - |
| 0098 |  | Spring-tank | $27.78 RepairClinic |
| 0099 |  | Shaft seal | $54.68 PartSelect |
| 0100 | | Fixing kit | - |
| 0101 | | Screw | - |
| 0102 |  | Bearing set | - |
| 0105 |  | Shock absorber | $44.85 RepairClinic |
| 0106 |  | Pulley | $81.95 PartSelect |
| 0107 |  | Sealing | $43.34 ApplianceParts Pro |
| 0108 | | Lock-clamp | - |
| 0113 | | Front | - |
| 0114 | | Weight | - |
| 0121 | | 00029867NLA Sealing | Discontinued |
| 0125 | | Sealing | - |
| 0126 |  | fastening ring | - |
| 0128 | | Hose connection inlet | - |
| 0132 |  | Ball-sump | - |
| 0133 | | 00056774NLA Sealing | Discontinued |
| 0137 |  | Holder | $14.40 ApplianceParts Pro |
| 0145 | | Latch | - |
| 0146 |  | Drain Hose | - |
