Model
Bosch WFK8010GB/08
Washer
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WFK8010GB/08Washer
1 diagram47 parts
Parts Sections (1)
Diagram
Flaps & Holders, Screws (0038-0155)
Parts in Flaps & Holders, Screws (0038-0155)
48 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0038 |  | Holder | - |
| 0039 |  | Holder | $6.27 Parts Dr |
| 0040 | | Holder | - |
| 0041 | | 00029856NLA Clip-earth | Discontinued |
| 0042 | | Holder | - |
| 0048 |  | Holder | $40.72 PartSelect |
| 0049 |  | Foot | - |
| 0052 |  | Electric lock | - |
| 0055 |  | Kit to Attach Washer to Floor/Pedestal | $60.98 Parts Dr |
| 0058 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0060 |  | Window | $63.71 ApplianceParts Pro |
| 0064 | | 00474870NLA Case-rear part | Discontinued |
| 0072 |  | 00029863NLA Spring guide | Discontinued |
| 0074 | | Holder | - |
| 0076 | | Screw | - |
| 0077 |  | Screw | - |
| 0078 |  | Screw | $4.45 ApplianceParts Pro |
| 0079 | | Spring guide | - |
| 0081 |  | Spring-tank | - |
| 0082 |  | Spring-tank | $27.78 RepairClinic |
| 0083 |  | Shaft seal | $54.68 PartSelect |
| 0084 | | Fixing kit | - |
| 0085 | | Screw | - |
| 0086 |  | Holder | - |
| 0087 |  | Screw | $9.95 ApplianceParts Pro |
| 0088 |  | Bearing set | - |
| 0095 |  | Shock absorber | $44.85 RepairClinic |
| 0096 |  | Pulley | $81.95 PartSelect |
| 0097 |  | Sealing | $43.34 ApplianceParts Pro |
| 0098 | | Lock-clamp | - |
| 0102 | | Front | - |
| 0103 | | Weight | - |
| 0104 | | Bearing cross | - |
| 0108 |  | Belt-drive | - |
| 0113 |  | Stud | - |
| 0114 |  | Filter-water inlet | $17.16 Parts Dr |
| 0115 | | 00029867NLA Sealing | Discontinued |
| 0118 | | Sealing | - |
| 0121 |  | fastening ring | - |
| 0122 | | fastening ring | - |
| 0124 |  | Sealing | - |
| 0126 | | Hose connection inlet | - |
| 0130 |  | Ball-sump | - |
| 0131 | | 00056774NLA Sealing | Discontinued |
| 0135 |  | Holder | $14.40 ApplianceParts Pro |
| 0144 | | Latch | - |
| 0145 |  | Drain Hose | - |
| 0155 |  | Hose | $64.14 ApplianceParts Pro |
