Model
Bosch WFM3010GB/01
Washer
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WFM3010GB/01Washer
1 diagram31 parts
Parts Sections (1)
Diagram
Flaps & Holders, Hoses (0022-0115)
Parts in Flaps & Holders, Hoses (0022-0115)
31 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0022 |  | Holder | - |
| 0023 |  | Holder | $6.27 Parts Dr |
| 0024 | | Holder | - |
| 0025 | | 00029856NLA Clip-earth | Discontinued |
| 0026 | | Holder | - |
| 0032 |  | Foot | - |
| 0038 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0040 |  | Window | $63.71 ApplianceParts Pro |
| 0044 | | 00474870NLA Case-rear part | Discontinued |
| 0046 |  | Worktop | - |
| 0050 |  | 00029863NLA Spring guide | Discontinued |
| 0052 | | Holder | - |
| 0055 | | Screw | - |
| 0056 | | Spring guide | - |
| 0057 | | Fixing kit | - |
| 0058 | | Screw | - |
| 0064 |  | Pulley | $81.95 PartSelect |
| 0065 |  | Sealing | $43.34 ApplianceParts Pro |
| 0066 | | Lock-clamp | - |
| 0071 | | Front | - |
| 0072 | | Weight | - |
| 0079 | | 00029867NLA Sealing | Discontinued |
| 0083 | | Sealing | - |
| 0084 |  | fastening ring | - |
| 0086 | | Hose connection inlet | - |
| 0089 |  | Ball-sump | - |
| 0090 | | 00056774NLA Sealing | Discontinued |
| 0095 |  | Holder | $14.40 ApplianceParts Pro |
| 0103 | | Latch | - |
| 0104 |  | Drain Hose | - |
| 0115 |  | Sealing | - |
