Model
Bosch WFM3010GB/02
Washer
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WFM3010GB/02Washer
1 diagram34 parts
Parts Sections (1)
Diagram
Flaps & Holders, Hoses (0026-0123)
Parts in Flaps & Holders, Hoses (0026-0123)
34 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0026 |  | Holder | - |
| 0027 |  | Holder | $6.27 Parts Dr |
| 0028 | | Holder | - |
| 0029 | | 00029856NLA Clip-earth | Discontinued |
| 0030 | | Holder | - |
| 0036 |  | Foot | - |
| 0044 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0046 |  | Window | $63.71 ApplianceParts Pro |
| 0050 | | 00474870NLA Case-rear part | Discontinued |
| 0052 |  | Worktop | - |
| 0058 |  | 00029863NLA Spring guide | Discontinued |
| 0060 | | Holder | - |
| 0063 | | Screw | - |
| 0064 | | Spring guide | - |
| 0065 |  | Spring-tank | - |
| 0066 |  | Spring-tank | $27.78 RepairClinic |
| 0067 | | Fixing kit | - |
| 0068 | | Screw | - |
| 0073 |  | Pulley | $81.95 PartSelect |
| 0074 |  | Sealing | $43.34 ApplianceParts Pro |
| 0075 | | Lock-clamp | - |
| 0080 | | Front | - |
| 0081 | | Weight | - |
| 0088 | | 00029867NLA Sealing | Discontinued |
| 0091 | | Sealing | - |
| 0092 |  | fastening ring | - |
| 0094 | | Hose connection inlet | - |
| 0097 |  | Ball-sump | - |
| 0098 | | 00056774NLA Sealing | Discontinued |
| 0103 |  | Holder | $14.40 ApplianceParts Pro |
| 0111 | | Latch | - |
| 0112 |  | Drain Hose | - |
| 0121 |  | Hose | $64.14 ApplianceParts Pro |
| 0123 |  | Sealing | - |
