Model
Bosch WFM3010GB/08
Washer
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WFM3010GB/08Washer
1 diagram43 parts
Parts Sections (1)
Diagram
Flaps & Holders, Screws (0031-0142)
Parts in Flaps & Holders, Screws (0031-0142)
43 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0031 |  | Holder | - |
| 0032 |  | Holder | $6.27 Parts Dr |
| 0033 | | Holder | - |
| 0034 | | 00029856NLA Clip-earth | Discontinued |
| 0035 | | Holder | - |
| 0041 |  | Holder | $40.72 PartSelect |
| 0042 |  | Foot | - |
| 0048 |  | Kit to Attach Washer to Floor/Pedestal | $60.98 Parts Dr |
| 0051 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0053 |  | Window | $63.71 ApplianceParts Pro |
| 0057 | | 00474870NLA Case-rear part | Discontinued |
| 0064 |  | 00029863NLA Spring guide | Discontinued |
| 0066 | | Holder | - |
| 0068 | | Screw | - |
| 0069 |  | Screw | - |
| 0070 |  | Screw | $4.45 ApplianceParts Pro |
| 0071 | | Spring guide | - |
| 0073 |  | Spring-tank | - |
| 0074 |  | Spring-tank | $27.78 RepairClinic |
| 0075 | | Fixing kit | - |
| 0076 | | Screw | - |
| 0078 |  | Holder | - |
| 0084 |  | Shock absorber | $44.85 RepairClinic |
| 0085 |  | Pulley | $81.95 PartSelect |
| 0086 |  | Sealing | $43.34 ApplianceParts Pro |
| 0087 | | Lock-clamp | - |
| 0091 | | Front | - |
| 0092 | | Weight | - |
| 0096 |  | Belt-drive | - |
| 0100 |  | Stud | - |
| 0101 |  | Filter-water inlet | $17.16 Parts Dr |
| 0102 | | 00029867NLA Sealing | Discontinued |
| 0105 | | Sealing | - |
| 0108 |  | fastening ring | - |
| 0110 |  | Branching piece | - |
| 0111 |  | Sealing | - |
| 0113 | | Hose connection inlet | - |
| 0116 |  | Ball-sump | - |
| 0117 | | 00056774NLA Sealing | Discontinued |
| 0122 |  | Holder | $14.40 ApplianceParts Pro |
| 0131 | | Latch | - |
| 0132 |  | Drain Hose | - |
| 0142 |  | Hose | $64.14 ApplianceParts Pro |
