Model
Bosch WFM3410GB/03
Washer
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WFM3410GB/03Washer
1 diagram36 parts
Parts Sections (1)
Diagram
Flaps & Holders, Hoses (0036-0154)
Parts in Flaps & Holders, Hoses (0036-0154)
36 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0036 |  | Holder | - |
| 0037 |  | Holder | $6.27 Parts Dr |
| 0038 | | Holder | - |
| 0039 | | 00029856NLA Clip-earth | Discontinued |
| 0040 | | Holder | - |
| 0046 |  | Foot | - |
| 0051 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0053 |  | Window | $63.71 ApplianceParts Pro |
| 0056 | | 00474870NLA Case-rear part | Discontinued |
| 0057 |  | Worktop | - |
| 0088 |  | 00029863NLA Spring guide | Discontinued |
| 0090 | | Holder | - |
| 0093 | | Screw | - |
| 0094 |  | Screw | - |
| 0095 | | Spring guide | - |
| 0096 |  | Spring-tank | - |
| 0097 |  | Spring-tank | $27.78 RepairClinic |
| 0098 | | Fixing kit | - |
| 0099 | | Screw | - |
| 0103 |  | Shock absorber | $44.85 RepairClinic |
| 0104 |  | Pulley | $81.95 PartSelect |
| 0105 |  | Sealing | $43.34 ApplianceParts Pro |
| 0106 | | Lock-clamp | - |
| 0111 | | Front | - |
| 0112 | | Weight | - |
| 0119 | | 00029867NLA Sealing | Discontinued |
| 0122 | | Sealing | - |
| 0123 |  | fastening ring | - |
| 0125 | | Hose connection inlet | - |
| 0128 |  | Ball-sump | - |
| 0129 | | 00056774NLA Sealing | Discontinued |
| 0134 |  | Holder | $14.40 ApplianceParts Pro |
| 0142 | | Latch | - |
| 0143 |  | Drain Hose | - |
| 0152 |  | Hose | $64.14 ApplianceParts Pro |
| 0154 |  | Sealing | - |
