Model
Bosch WFM3420GB/15
Washer
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WFM3420GB/15Washer
1 diagram51 parts
Parts Sections (1)
Diagram
Flaps & Holders, Screws (0201-0549)
Parts in Flaps & Holders, Screws (0201-0549)
52 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0201 |  | Holder | $40.72 PartSelect |
| 0203 |  | 00474870NLA Case-rear part | Discontinued |
| 0204 | | Holder | - |
| 0211 | | 00029856NLA Clip-earth | Discontinued |
| 0212 | | Holder | - |
| 0215 | | Holder | - |
| 0216 |  | Holder | $6.27 Parts Dr |
| 0221 |  | Foot | - |
| 0222 |  | Kit to Attach Washer to Floor/Pedestal | $60.98 Parts Dr |
| 0227 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0229 |  | Window | $63.71 ApplianceParts Pro |
| 0231 |  | Electric lock | - |
| 0235 |  | Worktop | - |
| 0401 |  | Screw | $4.45 ApplianceParts Pro |
| 0402 |  | Pulley | $81.95 PartSelect |
| 0403 | | Bearing cross | - |
| 0404 |  | Screw | - |
| 0405 | | Screw | - |
| 0406 |  | Bearing set | - |
| 0407 |  | Shaft seal | - |
| 0408 |  | Spring-tank | - |
| 0409 |  | Spring guide | $18.95 ApplianceParts Pro |
| 0410 |  | Spring-tank | $27.78 RepairClinic |
| 0411 |  | 00029863NLA Spring guide | Discontinued |
| 0412 | | Spring guide | - |
| 0414 | | Fixing kit | - |
| 0418 | | Holder | - |
| 0419 |  | Sealing | $43.34 ApplianceParts Pro |
| 0420 | | Front | - |
| 0421 | | Weight | - |
| 0422 | | Lock-clamp | - |
| 0424 | | Screw | - |
| 0426 |  | Shock absorber | $44.85 RepairClinic |
| 0429 |  | Belt-drive | - |
| 0430 |  | Screw | $9.95 ApplianceParts Pro |
| 0431 |  | Holder | - |
| 0502 |  | Filter-water inlet | $17.16 Parts Dr |
| 0504 |  | Branching piece | - |
| 0505 | | 00029867NLA Sealing | Discontinued |
| 0506 | | Hose connection inlet | - |
| 0507 |  | Drain Hose | - |
| 0508 |  | Holder | $14.40 ApplianceParts Pro |
| 0509 |  | Stud | - |
| 0515 |  | Hose | $64.14 ApplianceParts Pro |
| 0516 | | 00056774NLA Sealing | Discontinued |
| 0517 |  | Ball-sump | - |
| 0518 |  | fastening ring | - |
| 0522 | | Latch | - |
| 0524 |  | Sealing | - |
| 0540 | | Sealing | - |
| 0543 | | fastening ring | - |
| 0549 |  | Quick descaler | - |
