Model
Bosch WFM3710GB/08
Washer
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WFM3710GB/08Washer
1 diagram45 parts
Parts Sections (1)
Diagram
Flaps & Holders, Screws (0036-0161)
Parts in Flaps & Holders, Screws (0036-0161)
45 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0036 |  | Holder | $40.72 PartSelect |
| 0037 |  | Holder | - |
| 0038 |  | Holder | $6.27 Parts Dr |
| 0039 | | Holder | - |
| 0040 | | 00029856NLA Clip-earth | Discontinued |
| 0041 | | Holder | - |
| 0047 |  | Foot | - |
| 0053 |  | Kit to Attach Washer to Floor/Pedestal | $60.98 Parts Dr |
| 0056 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0058 |  | Window | $63.71 ApplianceParts Pro |
| 0062 | | 00474870NLA Case-rear part | Discontinued |
| 0071 |  | 00029863NLA Spring guide | Discontinued |
| 0073 | | Holder | - |
| 0075 | | Screw | - |
| 0076 |  | Screw | - |
| 0077 |  | Screw | $4.45 ApplianceParts Pro |
| 0078 | | Spring guide | - |
| 0080 |  | Spring-tank | - |
| 0081 |  | Spring-tank | $27.78 RepairClinic |
| 0082 | | Fixing kit | - |
| 0083 | | Screw | - |
| 0085 |  | Holder | - |
| 0086 |  | Screw | $9.95 ApplianceParts Pro |
| 0092 |  | Shock absorber | $44.85 RepairClinic |
| 0093 |  | Pulley | $81.95 PartSelect |
| 0094 |  | Sealing | $43.34 ApplianceParts Pro |
| 0095 | | Lock-clamp | - |
| 0100 | | Front | - |
| 0101 | | Weight | - |
| 0105 |  | Belt-drive | - |
| 0109 |  | Stud | - |
| 0111 | | 00029867NLA Sealing | Discontinued |
| 0114 | | Sealing | - |
| 0117 |  | fastening ring | - |
| 0119 |  | Sealing | - |
| 0121 | | Hose connection inlet | - |
| 0124 |  | Ball-sump | - |
| 0125 | | 00056774NLA Sealing | Discontinued |
| 0127 |  | Holder | $14.40 ApplianceParts Pro |
| 0135 | | Latch | - |
| 0136 |  | Drain Hose | - |
| 0144 |  | Hose | $64.14 ApplianceParts Pro |
| 0153 |  | Spring guide | $18.95 ApplianceParts Pro |
| 0155 |  | Branching piece | - |
| 0161 |  | Filter-water inlet | $17.16 Parts Dr |
