Model
Bosch WFT2800GB/01
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WFT2800GB/01
1 diagram74 parts
Parts Sections (1)
Diagram
Flaps & Holders, Screws (0009-0548)
Parts in Flaps & Holders, Screws (0009-0548)
77 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0009 |  | Sealing | - |
| 0010 | | Sealing | - |
| 0016 |  | Spring | - |
| 0201 |  | Holder | $30.97 ApplianceParts Pro |
| 0202 | | Transit bolt | - |
| 0203 |  | Transit bolt | - |
| 0205 | | 00474870NLA Case-rear part | Discontinued |
| 0206 | | Holder | - |
| 0208 | | 00474870NLA Case-rear part | Discontinued |
| 0209 | | Housing | - |
| 0210 |  | Auxiliary tool | $11.39 ApplianceParts Pro |
| 0211 | | Case-bottom | - |
| 0212 |  | Foot | - |
| 0213 |  | Kit to Attach Washer to Floor/Pedestal | $60.98 Parts Dr |
| 0214 | | 00210150NLA Worktop | Discontinued |
| 0215 |  | Worktop | - |
| 0216 |  | Cover | - |
| 0217 |  | Guide | - |
| 0219 | | Holder | - |
| 0220 | | 00029856NLA Clip-earth | Discontinued |
| 0221 | | Holder | - |
| 0222 | | Clip | - |
| 0224 |  | Holder | $6.27 Parts Dr |
| 0226 | | 00029856NLA Clip-earth | Discontinued |
| 0233 | | Front panel | - |
| 0234 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0239 |  | Hinge-window | - |
| 0402 |  | Screw | $4.45 ApplianceParts Pro |
| 0403 |  | Pulley | $81.95 PartSelect |
| 0404 | | Screw | - |
| 0405 |  | Shaft seal | $54.68 PartSelect |
| 0406 |  | Bearing set | - |
| 0407 | | Bearing cross | - |
| 0408 |  | Spring-tank | - |
| 0409 |  | Spring guide | $18.95 ApplianceParts Pro |
| 0410 |  | Spring-tank | $27.78 RepairClinic |
| 0411 |  | 00029863NLA Spring guide | Discontinued |
| 0412 | | Tub | - |
| 0413 | | Spring guide | - |
| 0414 | | Fixing kit | - |
| 0415 | | 00207803NLA Drum | Discontinued |
| 0416 |  | Sealing | $43.34 ApplianceParts Pro |
| 0417 | | Front | - |
| 0418 | | Weight | - |
| 0419 | | Lock-clamp | - |
| 0423 | | Screw | - |
| 0426 |  | Belt-drive | - |
| 0427 |  | Screw | $9.95 ApplianceParts Pro |
| 0428 |  | Holder | - |
| 0429 | | Screw | - |
| 0437 | | Cover | - |
| 0438 |  | Shock absorber | $44.85 RepairClinic |
| 0439 | | Holder | - |
| 0440 |  | Agitator paddle laundry | $10.95 ApplianceParts Pro |
| 0441 |  | Screw | - |
| 0502 |  | Filter-water inlet | $17.16 Parts Dr |
| 0507 | | Hose connection inlet | - |
| 0508 | | 00029867NLA Sealing | Discontinued |
| 0509 |  | Hose-vent | $35.33 ApplianceParts Pro |
| 0511 |  | Hose | $64.14 ApplianceParts Pro |
| 0512 | | 00056774NLA Sealing | Discontinued |
| 0513 |  | Ball-sump | - |
| 0514 |  | fastening ring | - |
| 0518 | | Latch | - |
| 0526 | | Sealing | - |
| 0528 | | fastening ring | - |
| 0530 |  | Drain Hose | - |
| 0531 |  | Stud | - |
| 0532 |  | Holder | $14.40 ApplianceParts Pro |
| 0534 |  | Hose-pressure chamber | $12.95 ApplianceParts Pro |
| 0536 | | 00069164NLA Sealing | Discontinued |
| 0538 | | Sealing | - |
| 0540 | | 00095269NLA Sieve | Discontinued |
| 0542 | | Sealing | - |
| 0544 | | Filter-fluff | $20.93 Part Advantage |
| 0546 |  | Branching piece | - |
| 0548 |  | Valve | - |
