Model
Bosch WFT7010GB/08
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WFT7010GB/08
1 diagram41 parts
Parts Sections (1)
Diagram
Flaps & Holders, Hoses (0021-0149)
Parts in Flaps & Holders, Hoses (0021-0149)
44 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0021 |  | Holder | - |
| 0022 |  | Holder | $6.27 Parts Dr |
| 0023 | | Holder | - |
| 0024 | | 00029856NLA Clip-earth | Discontinued |
| 0025 | | 00029856NLA Clip-earth | Discontinued |
| 0026 | | Holder | - |
| 0032 |  | Holder | $30.97 ApplianceParts Pro |
| 0033 |  | Foot | - |
| 0042 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0046 | | 00474870NLA Case-rear part | Discontinued |
| 0048 |  | Worktop | - |
| 0079 |  | 00029863NLA Spring guide | Discontinued |
| 0081 | | Holder | - |
| 0082 | | Screw | - |
| 0084 |  | Screw | - |
| 0086 | | Spring guide | - |
| 0087 |  | Spring-tank | - |
| 0088 |  | Spring-tank | $27.78 RepairClinic |
| 0089 |  | Shaft seal | $54.68 PartSelect |
| 0090 | | Fixing kit | - |
| 0091 | | Screw | - |
| 0092 |  | Holder | - |
| 0093 |  | Screw | $9.95 ApplianceParts Pro |
| 0094 |  | Bearing set | - |
| 0100 |  | Shock absorber | $44.85 RepairClinic |
| 0101 |  | Pulley | $81.95 PartSelect |
| 0102 |  | Sealing | $43.34 ApplianceParts Pro |
| 0103 | | Lock-clamp | - |
| 0104 | | Lock-clamp | - |
| 0107 | | Front | - |
| 0108 | | Weight | - |
| 0109 | | Bearing cross | - |
| 0114 |  | Belt-drive | - |
| 0117 | | 00029867NLA Sealing | Discontinued |
| 0120 | | Sealing | - |
| 0121 |  | fastening ring | - |
| 0122 | | fastening ring | - |
| 0124 | | Hose connection inlet | - |
| 0127 |  | Ball-sump | - |
| 0128 | | 00056774NLA Sealing | Discontinued |
| 0131 |  | Holder | $14.40 ApplianceParts Pro |
| 0139 | | Latch | - |
| 0140 |  | Drain Hose | - |
| 0149 |  | Hose | $64.14 ApplianceParts Pro |
