Model
Bosch WIT7410GB/08
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WIT7410GB/08
1 diagram42 parts
Parts Sections (1)
Diagram
Screws, Flaps & Holders (0010-0174)
Parts in Screws, Flaps & Holders (0010-0174)
43 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0010 |  | Spring | - |
| 0027 |  | Holder | - |
| 0028 | | Holder | - |
| 0029 | | 00029856NLA Clip-earth | Discontinued |
| 0030 | | Holder | - |
| 0040 |  | Foot | - |
| 0051 |  | Kit to Attach Washer to Floor/Pedestal | $60.98 Parts Dr |
| 0056 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0059 | | 00474870NLA Case-rear part | Discontinued |
| 0096 |  | 00029863NLA Spring guide | Discontinued |
| 0098 | | Holder | - |
| 0100 | | Screw | - |
| 0102 |  | Screw | - |
| 0104 |  | Screw | $4.45 ApplianceParts Pro |
| 0105 | | Spring guide | - |
| 0107 |  | Spring-tank | - |
| 0108 |  | Spring-tank | $27.78 RepairClinic |
| 0109 |  | Shaft seal | $54.68 PartSelect |
| 0110 | | Fixing kit | - |
| 0111 | | Screw | - |
| 0112 |  | Screw | $9.95 ApplianceParts Pro |
| 0113 |  | Bearing set | - |
| 0119 |  | Shock absorber | $44.85 RepairClinic |
| 0120 |  | Pulley | $81.95 PartSelect |
| 0121 |  | Sealing | $43.34 ApplianceParts Pro |
| 0122 | | Lock-clamp | - |
| 0125 | | Front | - |
| 0126 | | Weight | - |
| 0127 | | Bearing cross | - |
| 0132 |  | Belt-drive | - |
| 0136 |  | Stud | - |
| 0137 |  | Filter-water inlet | $17.16 Parts Dr |
| 0138 | | 00029867NLA Sealing | Discontinued |
| 0143 |  | fastening ring | - |
| 0144 | | fastening ring | - |
| 0146 |  | Sealing | - |
| 0148 | | Hose connection inlet | - |
| 0151 |  | Ball-sump | - |
| 0152 | | 00056774NLA Sealing | Discontinued |
| 0156 |  | Holder | $14.40 ApplianceParts Pro |
| 0164 | | Latch | - |
| 0165 |  | Drain Hose | - |
| 0174 |  | Hose | $64.14 ApplianceParts Pro |
