Model
Bosch WIT7420GB/08
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WIT7420GB/08
1 diagram42 parts
Parts Sections (1)
Diagram
Screws, Flaps & Holders (0006-0168)
Parts in Screws, Flaps & Holders (0006-0168)
43 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0006 |  | Spring | - |
| 0022 |  | Holder | - |
| 0023 | | Holder | - |
| 0024 | | 00029856NLA Clip-earth | Discontinued |
| 0025 | | Holder | - |
| 0035 |  | Foot | - |
| 0046 |  | Kit to Attach Washer to Floor/Pedestal | $60.98 Parts Dr |
| 0051 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0054 | | 00474870NLA Case-rear part | Discontinued |
| 0091 |  | 00029863NLA Spring guide | Discontinued |
| 0093 | | Holder | - |
| 0095 | | Screw | - |
| 0097 |  | Screw | - |
| 0099 |  | Screw | $4.45 ApplianceParts Pro |
| 0100 | | Spring guide | - |
| 0102 |  | Spring-tank | - |
| 0103 |  | Spring-tank | $27.78 RepairClinic |
| 0104 |  | Shaft seal | $54.68 PartSelect |
| 0105 | | Fixing kit | - |
| 0106 | | Screw | - |
| 0107 |  | Screw | $9.95 ApplianceParts Pro |
| 0108 |  | Bearing set | - |
| 0114 |  | Shock absorber | $44.85 RepairClinic |
| 0115 |  | Pulley | $81.95 PartSelect |
| 0116 |  | Sealing | $43.34 ApplianceParts Pro |
| 0117 | | Lock-clamp | - |
| 0120 | | Front | - |
| 0121 | | Weight | - |
| 0122 | | Bearing cross | - |
| 0126 |  | Belt-drive | - |
| 0130 |  | Stud | - |
| 0131 |  | Filter-water inlet | $17.16 Parts Dr |
| 0132 | | 00029867NLA Sealing | Discontinued |
| 0137 |  | fastening ring | - |
| 0138 | | fastening ring | - |
| 0140 |  | Sealing | - |
| 0142 | | Hose connection inlet | - |
| 0145 |  | Ball-sump | - |
| 0146 | | 00056774NLA Sealing | Discontinued |
| 0150 |  | Holder | $14.40 ApplianceParts Pro |
| 0158 | | Latch | - |
| 0159 |  | Drain Hose | - |
| 0168 |  | Hose | $64.14 ApplianceParts Pro |
