Model
Bosch WIT8440GB/08
Parts Sections (1)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelBosch
WIT8440GB/08
1 diagram55 parts
Parts Sections (1)
Diagram
Screws, Hoses (0011-0543)
Parts in Screws, Hoses (0011-0543)
57 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 0011 |  | Spring | - |
| 0034 |  | Quick descaler | - |
| 0205 |  | 00474870NLA Case-rear part | Discontinued |
| 0206 | | Holder | - |
| 0216 |  | Foot | - |
| 0219 | | 00029856NLA Clip-earth | Discontinued |
| 0220 | | Holder | - |
| 0223 | | Holder | - |
| 0236 |  | Lock-clamp | $21.68 ApplianceParts Pro |
| 0240 |  | Electric lock | - |
| 0249 | | Clip | - |
| 0260 | | Transit bolt | - |
| 0261 |  | Transit bolt | - |
| 0263 | | 00474870NLA Case-rear part | Discontinued |
| 0264 |  | Auxiliary tool | $11.39 ApplianceParts Pro |
| 0402 |  | Screw | $4.45 ApplianceParts Pro |
| 0403 |  | Pulley | $81.95 PartSelect |
| 0404 |  | Screw | - |
| 0407 |  | Belt-drive | - |
| 0408 |  | Screw | $9.95 ApplianceParts Pro |
| 0409 |  | Holder | - |
| 0411 | | Screw | - |
| 0412 |  | Shaft seal | $54.68 PartSelect |
| 0413 | | Bearing cross | - |
| 0414 | | Spring guide | - |
| 0415 |  | Bearing set | - |
| 0419 |  | Shock absorber | $44.85 RepairClinic |
| 0420 |  | Spring-tank | - |
| 0421 |  | Spring guide | $18.95 ApplianceParts Pro |
| 0422 |  | 00029863NLA Spring guide | Discontinued |
| 0423 |  | Spring-tank | $27.78 RepairClinic |
| 0425 | | Fixing kit | - |
| 0426 | | 00207803NLA Drum | Discontinued |
| 0428 | | Holder | - |
| 0429 |  | Sealing | $43.34 ApplianceParts Pro |
| 0430 | | Front | - |
| 0431 | | Weight | - |
| 0432 | | Lock-clamp | - |
| 0436 | | Screw | - |
| 0501 | | Hose connection inlet | - |
| 0502 | | 00029867NLA Sealing | Discontinued |
| 0504 |  | Hose | $64.14 ApplianceParts Pro |
| 0506 | | Sealing | - |
| 0511 | | 00095269NLA Sieve | Discontinued |
| 0513 |  | Hose-vent | $35.33 ApplianceParts Pro |
| 0514 | | 00056774NLA Sealing | Discontinued |
| 0515 |  | Ball-sump | - |
| 0516 |  | fastening ring | - |
| 0520 | | Latch | - |
| 0526 | | fastening ring | - |
| 0528 |  | Drain Hose | - |
| 0529 |  | Holder | $14.40 ApplianceParts Pro |
| 0530 |  | Stud | - |
| 0535 |  | Hose-pressure chamber | $12.95 ApplianceParts Pro |
| 0537 | | 00069164NLA Sealing | Discontinued |
| 0538 |  | Branching piece | - |
| 0543 |  | Filter-water inlet | $17.16 Parts Dr |
