Model
Kenmore 253.51692100
Side-By-Side Refrigerator (Kenmore 25351692100)
Parts Sections (10)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelKenmore
253.51692100Side-By-Side Refrigerator (Kenmore 25351692100)
10 diagrams338 parts
Parts Sections (10)
Diagram
All Parts
Parts in All Parts
16 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| NI |  | Refrigerator Technical Data Sheet | $7.95 ApplianceParts Pro |
| NI |  | 241860803replaces 218842802 Refrigerator Bucket | $95.28 Part Advantage |
| NI |  | Refrigerator Wiring Harness | - |
| NI |  | 240545201replaces 240352101 Refrigerator Connector | $42.65 Part Advantage |
| NI |  | 5303918277replaces 240352401 Refrigerator Ice Maker | $47.66 Part Advantage |
| NI | | Refrigerator Service Data Sheet | - |
| NI | | Refrigerator Owner's Manual | - |
| NI | | Refrigerator Electronic Harness | - |
| NI | | Refrigerator Guard | $59.32 ApplianceParts Pro |
| NI |  | 5303321319replaces 5303305324 Touch Paint | $8.35 Part Advantage |
| NI |  | 5303321321replaces 5303305345 Touch Paint | $12.32 Part Advantage |
| NI |  | 5303918328replaces 5303918218 Heat Exchanger | $204.47 Part Advantage |
| NI | | 5303918222NLA Refrigerator Hot Tube Repair Kit | Discontinued |
| NI |  | Appliance Touch-Up Paint, 0.6-oz (Bisque) | $30.84 RepairClinic |
| NI | – | 5995351151 Refrigerator Repair Parts List | - |
| NI |  | Clamp Tube (Black) | $14.76 ApplianceParts Pro |
