Model
Kenmore 253.56943602
Refrigerator (Kenmore 25356943602)
Parts Sections (9)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelKenmore
253.56943602Refrigerator (Kenmore 25356943602)
9 diagrams287 parts
Parts Sections (9)
Diagram
REFRIGERATOR DOOR
Parts in REFRIGERATOR DOOR
12 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 2 |  | 241786013replaces 241674805 Refrigerator Gasket | $54.70 Parts Dr |
| 4 |  | Kenmore Refrigerator Door Bin | $17.34 Part Advantage |
| 7 |  | Refrigerator Dairy Door | Discontinued |
| 13 |  | Refrigerator Door Stop (Black) | $34.87 Part Advantage |
| 15 | | Ff Door Ss | - |
| 18 | | Refrigerator Door Handle | - |
| 21 |  | 216858001replaces 241696001 Refrigerator Screw | $9.94 ApplianceParts Pro |
| 21A |  | 5303323137replaces 240598401 Refrigerator Freezer Door Handle Screw | $8.39 ApplianceParts Pro |
| 22 |  | Refrigerator Door Hinge Bushing | $12.29 Part Advantage |
| 22B |  | Refrigerator Door Hinge Bearing (Black) | $13.22 Part Advantage |
| 49 |  | 240356401replaces 240356405 Refrigerator Door Bin | $47.14 Part Advantage |
| 75 | | 241696101NLA Refrigerator Handle Clip | Discontinued |
