Model
Tappan 95-1967-23-03
Refrigerator, Top Mount
Parts Sections (6)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelTappan
95-1967-23-03Refrigerator, Top Mount
6 diagrams165 parts
Parts Sections (6)
Diagram
FREEZER DOOR PARTS
Parts in FREEZER DOOR PARTS
19 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 1 | – | 3001719 FREEZER DOOR-ALMOND | - |
| 2 | – | 3200272 DOOR CLOSER (2) | - |
| 3 |  | 5303001020replaces G169729 SCREW-CLOSER MTG (NON-ILLUSTRATED) | - |
| 4 |  | 5303001022replaces G183139 BEARING, HINGE HOLE, UPPER | - |
| 4A | | HINGE BEARING-LOWER (NON-ILLUSTRATED) | Discontinued |
| 5 | – | 5303200474 GASKET-FRZR DOOR, MAGNETIC | - |
| 6 | – | 5303016719 DOOR PANEL-INNER | - |
| 6A |  | 218843801replaces G162585 SCREW | - |
| 7 | – | G161019-15 DOOR RACK (6) | - |
| 8 | | 5303016721replaces G161018-04 SUPPORT RS (6) | - |
| 9 | | 5316108004replaces G161080-04 SUPPORT LS (6) | - |
| 10 | – | G152308-01 PLUG-DOOR BOTTOM (NON-ILLUSTRATED) | - |
| 11 | | INSULATION-DOOR (BULK) (NON-ILLUSTRATED) | Discontinued |
| 12 | – | G175666-20 GRIP-HANDLE | - |
| 13 | – | G179809 END-HANDLE TOP | - |
| 14 | – | G175810 END-HANDLE BOTTOM (2) | - |
| 15 | | 5308011745replaces G185566 SCREW | - |
| 16 | | 5308000790replaces G165376 BUMPER-LIGHT SWITCH (2) | $1.83 RepairClinic |
| *35686 | | 218843801replaces G162585 SCREW | - |
