Model
Universal CE300SP2W01
Range/Oven, Electric, Freestanding
Parts Sections (4)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelUniversal
CE300SP2W01Range/Oven, Electric, Freestanding
4 diagrams89 parts
Parts Sections (4)
Diagram
DOOR PARTS
Parts in DOOR PARTS
15 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 1 |  | 316137003replaces 3016755 End Cap,handle ,black ,(2) | $30.95 Parts Dr |
| 2 |  | 5303273127NLA HANDLE-DOOR, BLACK, OVEN | Discontinued |
| 3 | | INSULATION-DOOR LINER | - |
| 4 | | SHIELD-INSULATION, WHITE | Discontinued |
| 5 | – | 5303209318 LINER - OVEN DOOR SOL. | - |
| 6 | | SHIELD-INSULATION, BLACK | - |
| 7 | – | 5303272033 PANEL-OVEN DOOR-HARVEST WHEAT | - |
| 7 | – | 3202316 Panel,oven door ,almond | - |
| 7 | | PANEL, OVEN DOOR, WHITE | - |
| 8 |  | SEAL-OVEN DOOR, NON MSELF-CLEAN | $107.77 PartSelect |
| 9 | | 5303281378NLA SCREW-OVEN HANDLE, WAFER HD SQ DR, 10-24(F) X 3 | Discontinued |
| 10 | – | 3131210 CHANNEL-RETAINER (2) | - |
| *64111 |  | 5303300265replaces 5303212762 SCREW 8 X 18 X 1/2`` RH LOW PROOF DRAWER ASSY (9) | $10.70 ApplianceParts Pro |
| *64111 | – | 5303211157 PLATE, DOOR WEIGHT (NON-ILLUSTRATED) | - |
| *64111 |  | Screw,wafer hd sq dr ,8-18AB x 0.5 | - |
