Model
Frigidaire GCRG3038ADB
Gas Range
Parts Sections (5)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelFrigidaire
GCRG3038ADBGas Range
5 diagrams157 parts
Parts Sections (5)
Diagram
BACKGUARD
Parts in BACKGUARD
15 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 1 |  | Shield,backguard ,rear wall | - |
| 2 |  | Shield,backguard ,inner | $22.46 RepairClinic |
| 15 |  | Cap,end ,black ,RH | $41.91 Parts Dr |
| 15A |  | Cap,end ,black ,LH | $24.79 RepairClinic |
| 19 | | Panel,backguard ,black stainless | $136.95 ApplianceParts Pro |
| 20 |  | 5304533941replaces 5304521189 Controller,electronic ,ES334ISB | $68.74 Part Advantage |
| 20A |  | Overlay,EOC ,black ,ES335 | $30.43 Parts Dr |
| 36 |  | Knob,black stainless | $48.80 Parts Dr |
| 40 | | 316606128replaces 316606127 Panel-manifold,black stainless | $64.34 RepairClinic |
| 42 | | Deflector,backguard | - |
| 56 |  | Shield,backguard ,inner | $45.67 ApplianceParts Pro |
| NI |  | 316021109replaces 316021105 Screw,hex head cup pt ,8-18 x 0.375 ,black | $8.20 Part Advantage |
| NI |  | 131243700replaces 316021108 Screw,cup pt ,8-18 x 0.375 ,chrome | $1.96 Part Advantage |
| NI | | Screw,8-18 x 0.5 ,chrome | $8.20 Part Advantage |
| NI |  | Screw,10-16 x .486 | $7.79 Part Advantage |
