Model
Kenmore 363.58251890
Refrigerator (Kenmore 36358251890)
Parts Sections (11)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelKenmore
363.58251890Refrigerator (Kenmore 36358251890)
11 diagrams287 parts
Parts Sections (11)
Diagram
ICEMAKER WR30X0327
Parts in ICEMAKER WR30X0327
21 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 1A | – | SR6167 Refrigerator Owner's Manual | - |
| 1B | – | 31-51136 Refrigerator Mini Manual | - |
| 1C |  | Refrigerator Owner's Manual | $2.56 RepairClinic |
| 1D | – | SR1224 Energy Guide Label | - |
| 1E | – | SR3811 Refrigerator Parts List | - |
| 3 | | WR2X8669replaces WR02X8669 Refrigerator Fastener Tub | - |
| 6 | | Refrigerator Handle Trim | - |
| 7 | – | WR12X10053 Handle Sxs A | - |
| 11 | | Refrigerator Dispenser Trim (Black) | - |
| 12 | | Stop Door Wh | Discontinued |
| 13A | – | WR02X4599 Refrigerator Nut Strip | - |
| 13B | | WR02X7490NLA Shim Cam | Discontinued |
| 14 | | Refrigerator Door Gasket | Discontinued |
| 15 | – | WR17X3119 Refrigerator Retainer Strip | - |
| 16 |  | WR2X4901replaces WR02X4901 Refrigerator Riser Cam | $13.74 Part Advantage |
| 18 | | Refrigerator Retainer Strip | Discontinued |
| 19 | – | WR77X0600 I.d.panel Fz | - |
| 21 | | Door Front | - |
| 23 | | Door Front | - |
| 29 | | WR23X0443NLA Refrigerator Drive Hinge Harness | Discontinued |
| 34 | – | WR23X0457 Harness Light Switch | - |
