Model
Kenmore 363.59479990
Refrigerator (Kenmore 36359479990)
Parts Sections (11)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelKenmore
363.59479990Refrigerator (Kenmore 36359479990)
11 diagrams387 parts
Parts Sections (11)
Diagram
All Parts
Parts in All Parts
16 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| NI |  | Refrigerator Screw | - |
| NI | | WB17X5059NLA Refrigerator Block | Discontinued |
| NI |  | Block | - |
| NI | | Connection Block | - |
| NI | | HOUSING TERMINAL | - |
| NI |  | WD2X323Dreplaces WD2X323 SCR 8-32X1/4 #6 TRUSS HD | - |
| NI |  | WR01X10019replaces WR1X10019 Refrigerator Screw | $7.95 ApplianceParts Pro |
| NI |  | WR01X10065replaces WR1X10065 Scr 8-18 | $7.18 Parts Dr |
| NI | – | WR1X10123 Scr 6-19 | - |
| NI | | WE2X186Dreplaces WR1X1194 Screw, 2-pack | - |
| NI | – | WR1X1825 Refrigerator Fastener | - |
| NI |  | WE02X10011replaces WR1X1966 Refrigerator Screw | - |
| NI | | WZ4X230Dreplaces WZ4X230 MTG. SCREW - I.M. | - |
| NI |  | WZ4X241Dreplaces WZ4X241 SCR 8-15 AB TR 1/2 SS | $14.87 Part Advantage |
| NI |  | WD2X5166replaces WZ4X263 MOUNT SCREW 10-16X1/2 | $9.92 Parts Dr |
| NI | | Refrigerator Screw | $12.79 ApplianceParts Pro |
