Model
Hotpoint CTX18AKER
Refrigerator
Parts Sections (3)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelHotpoint
CTX18AKERRefrigerator
3 diagrams184 parts
Parts Sections (3)
Diagram
Parts List
Parts in Parts List
74 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 1 | – | 31-5025 REF INSTALL INST | - |
| 1 | – | 39-6305 PM RVSBL HDW INST | - |
| 3 |  | WR2X4990replaces WR02X3757 FASTENER TUBULAR | $8.95 ApplianceParts Pro |
| 4 | – | WR77X0516 FRZ INNER DOOR | - |
| 5 | | WR12X0463NLA HANDLE DOOR | Discontinued |
| 6 | – | WR12X0645 STIFFENER HANDLE | - |
| 7 | – | WR12X0582 STIFFENER HANDLE | - |
| 8 | | WR02X7793NLA SHIM HANDLE ASM | Discontinued |
| 10 | | WR02X7140NLA CLIP HANDLE | Discontinued |
| 11 | – | WZ04X0352 SCREW 8-18 B 7/16 | - |
| 12 | | WR12X643replaces WR12X0643 CHANNEL HANDLE | - |
| 13 | | WR2X7909replaces WR02X7909 SHIM HANDLE DOOR | - |
| 14 | – | WR02X4946 SHIM HANDLE DOOR | - |
| 16 | | WR1X1565Dreplaces WR01X1565 SCR 8-32 MA FL 21/32 S | - |
| 18 |  | WR1X1726Dreplaces WR01X1726 SCR 10-16 AB 3/4 SS | $23.52 Part Advantage |
| 19 | | FRONT DOOR SHELF | - |
| 21 |  | WR2X7674replaces WR02X7674 CAP SHELF FRT | - |
| 23 |  | WR24X449replaces WR24X0449 GASKET DOOR FZ WH | $127.78 Part Advantage |
| 24 | | RETAINER STRIP H | - |
| 25 | | RETAINER STRIP V | - |
| 26 | | WR02X7628NLA DOOR STOP | Discontinued |
| 28 | – | WR02X7627 THIMBLE WH | - |
| 29 | – | WR02X7618 PLUG BUTTON WHITE | - |
| 30 | | WR1X5475replaces WR01X5475 SCR 8/10-16 AB PA 5/8 | - |
| 35 | – | WR12X0644 DOOR HANDLE INSERT | - |
| 103 | – | WR77X0515 FF INNER DOOR | - |
| 104 |  | WR24X450replaces WR24X0450 GASKET DOOR FF | $107.53 Part Advantage |
| 105 | | CAP SHELF FRT | Discontinued |
| 107 | – | WR22X0371 DAIRY DOOR | - |
| 109 | – | WR71X1866 FRONT DOOR SHELF | - |
| 110 |  | CAP TRIM HANDLE | Discontinued |
| 111 | | WR02X7792NLA CAP TRIM HANDLE | Discontinued |
| 112 | | WR04X0180NLA NAMEPLATE DR RSV(WH) | Discontinued |
| 115 | | RETAINER STRIP V | - |
| 118 | | WR19X5003NLA DISH BUTTER | Discontinued |
| 119 | – | WR02X4928 CAP HANDLE | - |
| 120 | | WR01X1755NLA SCR 8-18 AB SPECIAL PA S | Discontinued |
| 121 | | WR12X509replaces WR12X0509 INSERT DOOR HANDLE(BRN) | - |
| 125 | | WR12X0471NLA CHANNEL HANDLE | Discontinued |
| 125 | – | WR71X1863 FRONT DOOR SHELF | - |
| 150 |  | WR1X1791Dreplaces WR01X1751 SCREW | $22.07 RepairClinic |
| 208 | – | WR38X1132 TRIM SHELF | - |
| 211 | | SUPPORT SHELF | Discontinued |
| 214 |  | WR02X11760replaces WR02X7148 PLUG BUTTON | $5.09 Part Advantage |
| 215 | | WR32X0897NLA BUCKET UTILITY WH | Discontinued |
| 265 | | WR01X1774NLA AXLE WHEEL REAR | Discontinued |
| 284 | – | WR02X8069 CAP BTM CORNER | - |
| 352 |  | WR30X10154replaces WR30X5112 WR30X291 | $16.41 Part Advantage |
| 354 | | WR2X7289replaces WR02X7290 RETAINER-FASTENER | - |
| 435 |  | 40A15replaces STD372402 LAMP 40W 120V | $8.96 Parts Dr |
| 452 | – | WR02X8077 SHIM HINGE BTM | - |
| 551 | | WZ04X0244NLA SCREW-FRONT | Discontinued |
| 566 | | WR01X1487NLA SCREW | Discontinued |
| 602 |  | WR1X1591replaces WR01X1591 SCR 1/4-14 X 3/4 | - |
| 606 | – | WR17X2385 FRONT LINER FZ | - |
| 620 |  | WR50X60replaces WR50X0111 THERMOSTAT DEF | $8.27 Part Advantage |
| 648 |  | WR9X502replaces WR09X0419 CONTROL DEF | $63.48 Part Advantage |
| 689 | | WZ5X246replaces WZ05X0246 SCR 8-32 SPEC DRILL PT | $12.79 ApplianceParts Pro |
| 725 | – | WR87X0241 HI SIDE ASM | - |
| 744 | – | WR02X7278 CLIP COND-UPPER | - |
| 800 |  | WR57X10033replaces WR57X0095 WATER VALVE ASM | $28.64 Part Advantage |
| 801 | – | WR62X0044 COIL-ICE | - |
| 805 |  | WR1X5278replaces WR02X3736 STR RELIEF | $8.59 Parts Dr |
| 808 |  | WR2X4039replaces WR02X4039 ADHESIVE CLIP | $15.95 ApplianceParts Pro |
| 815 | – | WR57X0073 SCREEN & WASHER PKG. | - |
| 820 |  | WR30X10093replaces WR30X0259 NO DESCRIPTION | $168.04 Parts Dr |
| 900 | | WR78X8727replaces WR78X7983 FRZ O.DOOR (WH) | - |
| 900 | | WR78X8725replaces WR78X7984 FRZ O.DOOR AD | - |
| 900 | – | WR78X7985 FRZ O.DOOR (HA) | - |
| 910 | – | WR78X7986 FF O.DOOR (WH) | - |
| 910 | – | WR78X7987 FF O.DOOR (AD) | - |
| 910 | – | WR78X7988 FF O.DOOR (HA) | - |
| 921 | | WR02X7624NLA PLUG BUTTON WH | Discontinued |
| 32767 | – | 39-6260 PM GUIDE OWNERS | - |
