Model
GE JHP56N*K2
Range With Microwave Combo
Parts Sections (3)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelGE
JHP56N*K2Range With Microwave Combo
3 diagrams260 parts
Parts Sections (3)
Diagram
Parts List
Parts in Parts List
32 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 122 | – | WB02X1422 CLAMP HARNESS | - |
| 148 |  | WB1X536replaces WB01X5763 SCREW | $16.81 Parts Dr |
| 250 | – | WB02X3229 BARRIER BAKEUNIT OPENING | - |
| 263 |  | WB02X6195NLA PIN HINGE DOOR | Discontinued |
| 282 | – | WB02X6215 CLAMP HARNESS | - |
| 456 |  | WZ4X345Dreplaces WZ04X0345 SCREW 8-18X5/8 HXW | - |
| 459 |  | WB1X537replaces WB01X0537 SCREW | - |
| 461 | | WB1X536replaces WB01X0593 SCREW - DOOR ASM (4 PER) | $16.81 Parts Dr |
| 851 | – | WB26X5083 BLOWER MOTOR | - |
| 864 | – | WB56X6074 HOOD BODY WH | - |
| 864 | – | WB56X6075 HOOD BODY HA | - |
| 864 | – | WB56X6076 HOOD BODY AD | - |
| 871 | | WB02X7758NLA FILTER GREASE | Discontinued |
| 872 | – | WB02X1583 CLIP HOOD FILTER | - |
| 873 | | WB15X0109NLA HOOD PANEL HANDLE | Discontinued |
| 880 | – | WB56X0923 HOOD PANEL | - |
| 881 | – | WB02X7776 FILTER PLATE | - |
| 882 | | WB07X6793NLA TRIM HOOD | Discontinued |
| 883 | – | WB02X3432 PAD | - |
| 883 | – | WB07X0770 END CAP-RT | - |
| 883 | – | WB07X0771 END CAP-LT | - |
| 884 | – | WB02X2017 COVER BACK | - |
| 885 | – | WB02X3131 SPRING PIN ASM | - |
| 902 | – | WB49X5391 PLENUM AIR | - |
| 916 | – | WB02X7759 COVER | - |
| 936 | – | WB02X7692 FILTER COMBINATION | - |
| 940 | – | WB02X7760 COVER HOUSING | - |
| 989 | – | WB01X0425 SCREW | - |
| 1201 |  | WB1X5364replaces WB01X5364 SCREW (CR) | $5.09 Part Advantage |
| 32767 | – | 31-0632 INSTALL INSTRUCTIONS | - |
| 32767 | – | 31-0638 INSTALL INSTRUCTIONS | - |
| 32767 | – | 49-4801 MANUAL USERS | - |
