Model
GE JHP67G*D1
Range With Microwave Combo
Parts Sections (3)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelGE
JHP67G*D1Range With Microwave Combo
3 diagrams429 parts
Parts Sections (3)
Diagram
BLOWER PARTS ONLY
Parts in BLOWER PARTS ONLY
96 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 2 |  | WZ4X345Dreplaces WZ04X0231 SCREW MTG. GUIDE | - |
| 3 |  | WB21X36771replaces WB21X5243 SWITCH, INF SURFACE UNIT | $35.64 Part Advantage |
| 5 |  | WB02X3468NLA NEON LAMP 240V | Discontinued |
| 7 | – | WZ04X0289 SCR 8-18 AB HX 1/4 S | - |
| 8 | – | WZ02X0543 SCREW MT. BALL | - |
| 10 | – | WB01X0427 SCREW MT. BLOWER | - |
| 19 | – | WZ04X0419 SCR 10-16 AB HXW 5/8 S | - |
| 20 | – | WZ07X0030 NUT | - |
| 33 | – | WB01X0382 SCREW MT. BRACKET | - |
| 40 |  | WB1X500Dreplaces WZ04X0304 SCREW DUCT | $7.64 RepairClinic |
| 47 | – | WB02X3431 PAD (CUT TO SIZE) | - |
| 47 | – | WZ04X0217 SCR 6-20 B HXW 1/4 S | - |
| 50 | – | WB02X2630 CLIP | - |
| 89 | – | WZ05X0187 SCREW 8-32 X 1/2" PAN | - |
| 116 | – | WB02X3148 BRACKET CIRCUIT BOARD | - |
| 188 | – | WZ10X0114 LOCKWASHER | - |
| 250 | – | WB02X3229 BARRIER BAKEUNIT OPENING | - |
| 272 |  | BLOCK TERMINAL POWER | $69.99 Parts Dr |
| 280 |  | 40A15replaces WX12X1510 40A15 | $8.96 Parts Dr |
| 282 | – | WB24X5138 SWITCH, THERMAL (TLS) | - |
| 288 | | WZ4X345Dreplaces WZ04X0232 SCR 8-18 AB HXS 3/8 S | - |
| 303 |  | WB36X192replaces WB36X0389 OVEN LAMP LENS | $9.75 Part Advantage |
| 305 | – | WB02X6653 SPEEDNUT | - |
| 374 | – | WB02X3048 GASKET WINDOW | - |
| 402 | – | WB01X0591 SPEEDNUT | - |
| 520 | | WB02X3471NLA CLIP CAPILLARY TUBEOVEN | Discontinued |
| 652 | | WB02X1452NLA SUPPORT BROIL | Discontinued |
| 654 | – | WZ10X0114 LOCKWASHER | - |
| 701 | – | WB15X5133 HANDLE LATCH | - |
| 740 | – | WB02X7226 CLIP WIRE | - |
| 782 |  | TERMINAL BLOCK ASSY (2 P | - |
| 788 | – | WB17X5064 HOUSING SOCKET PKG 4 P1N | - |
| 788 | – | WB17X5079 HOUSING SOCKET PKG 6 PIN | - |
| 790 | – | WB01X0365 SPEEDNUT | - |
| 800 | | MOTOR ROTISSERIE | - |
| 851 | – | WB26X0027 MOTOR BLOWER | - |
| 852 | – | WB09X0072 SPRING DAMPER | - |
| 853 | – | WB49X0216 HOUSING BLOWER TOP | - |
| 854 | – | WB49X0217 HOUSING BLOWER BOTTOM | - |
| 855 | – | WB02X3239 STRAP | - |
| 856 | – | WB02X2235 DAMPER | - |
| 858 | – | WB02X3456 WHEEL BLOWER | - |
| 859 | – | WB02X3457 CLAMP | - |
| 860 | – | WB02X3458 CLAMP | - |
| 861 | – | WB02X1581 WIRE | - |
| 862 | – | WB02X2015 RETAINER | - |
| 863 | – | WB09X0073 SPRING BLOWER MOUNT | - |
| 864 | – | WB62X1499 HOOD BODY WH | - |
| 864 | – | WB62X1500 HOOD BODY CF | - |
| 864 | – | WB62X1501 HOOD BODY FA | - |
| 864 | – | WB62X1502 HOOD BODY HA | - |
| 864 | – | WB62X1503 HOOD BODY AD | - |
| 871 | – | WB02X6731 FILTER GREASE | - |
| 872 | – | WB02X1583 CLIP HOOD FILTER | - |
| 873 | | WB15X0109NLA HOOD PANEL HANDLE | Discontinued |
| 874 | – | WB49X0218 COVER INNER | - |
| 875 | – | WB49X0182 EXHAUST ASM | - |
| 876 | – | WB01X0426 STUD BALL | - |
| 877 | – | WB02X2016 RECEIVER STUD | - |
| 878 | – | WB49X0183 GUIDE AIR | - |
| 879 | – | WB49X0181 SUPPORT SLIDE | - |
| 880 | – | WB56X0923 HOOD PANEL | - |
| 881 | – | WB02X2629 PLATE FILTER | - |
| 882 | | WB07X0772NLA TRIM HOOD | Discontinued |
| 883 | – | WB02X3432 PAD | - |
| 883 | – | WB07X0770 END CAP-RT | - |
| 883 | – | WB07X0771 END CAP-LT | - |
| 884 | – | WB02X2017 COVER BACK | - |
| 885 | – | WB02X3131 SPRING PIN ASM | - |
| 910 | – | WB49X0180 DEFLECTOR AIR | - |
| 914 | – | WB02X7218 POST RH | - |
| 914 | – | WB02X7219 POST LH | - |
| 935 | – | WB24X0169 SWITCH LIGHT | - |
| 940 | – | WB49X0184 COVER ASM | - |
| 945 | – | WB02X3145 FINS MOTOR | - |
| 945 | – | WB02X3146 CLIP MOTOR FINS | - |
| 32767 | – | 31-0423 INSTALL INSTRUCTIONS | - |
| 32767 | | WB1X500Dreplaces WB01X0500 SCR 8-18 B HXW 1/4 S | $7.64 RepairClinic |
| 32767 | – | WB01X5508 WASHER | - |
| 32767 | – | WB01X5520 SPEEDNUT | - |
| 32767 | – | WB02X1511 INSULATION | - |
| 32767 | – | WB02X1579 PAD | - |
| 32767 | – | WB02X2107 SLEEVE DETENT | - |
| 32767 | – | WB02X3152 PAD | - |
| 32767 | – | WB02X3238 PAD | - |
| 32767 | – | WB02X6274 SLEEVE | - |
| 32767 | – | WB02X6496 INSULATION | - |
| 32767 | – | WB02X6659 PAD | - |
| 32767 | – | WB07X5645 TRIM COOKTOP FRONT | - |
| 32767 | | WB17X171replaces WB17X0171 TERMINAL MALE & FEMALE | - |
| 32767 | – | WZ04X0255 SCR 8-18X1 AB OVR 1/2 S | - |
| 32767 | | WZ4X248replaces WZ04X0361 SCREW MTG. TRIM LAMP | - |
| 32767 | – | WZ04X0372 SCR 6-20 AB HXW 3/8 S | - |
| 32767 | – | WZ04X0413 SCREW | - |
| 32767 | – | WZ05X0120 SCREW | - |
| 32767 | – | WZ06X0082 SCR 8-18 B HXW 3/8 S | - |
