Model
Kenmore 66513209N413
Dishwasher (Kenmore 66513209N413)
Parts Sections (10)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelKenmore
66513209N413Dishwasher (Kenmore 66513209N413)
10 diagrams154 parts
Parts Sections (10)
Diagram
CONTROL PANEL AND LATCH PARTS
Parts in CONTROL PANEL AND LATCH PARTS
16 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 1 |  | W10605164replaces W11082346 CONSOLE ASM- | - |
| 1A |  | W10605165replaces W11082347 CONSOLE ASM- | - |
| 1B | | W10605166replaces W11082348 CONSOLE ASM- | - |
| 2 |  | W11305293replaces W10825638 YODA2 CONNEC | $142.25 Parts Dr |
| 3 | | W11305293replaces W10825369 YODA2 BRACE | $142.25 Parts Dr |
| 4 | | W11087214replaces W10913612 CTRL-YD2-N25 | - |
| 5 | – | W10918476 Housing Assembly | - |
| 6 |  | W11028004replaces W10566903 Dishwasher User Interface Wire Harness | $7.97 Part Advantage |
| 7 | | W11232015replaces W10648588 Dishwasher Screw | $9.95 ApplianceParts Pro |
| 8 | | W11673298replaces W10313267 Dishwasher Door Handle | $35.34 Parts Dr |
| 8A |  | Dishwasher Door Handle | $33.03 Parts Dr |
| 8B |  | Handle (Off-White) | - |
| 9 |  | WPW10653840replaces W10574864 Dishwasher Door Latch | $12.94 Part Advantage |
| 10 | | Dishwasher User Interface Control Button Assembly | - |
| 11 |  | W10815836replaces W10485367 Dishwasher Control Panel Clip | $2.30 Part Advantage |
| 12 |  | W11256107replaces W10195237 Dishwasher Control Board Clip | $23.60 PartSelect |
