Model
Kenmore 66513262K111
Undercounter Dishwasher (Kenmore 66513262K111)
Parts Sections (12)
How to find your part
Find part on diagram
Zoom in & tap a highlighted area
Tap "Parts" tab
Switch to the parts list view
See details & prices
Your selected part is highlighted
ModelKenmore
66513262K111Undercounter Dishwasher (Kenmore 66513262K111)
12 diagrams156 parts
Parts Sections (12)
Diagram
DOOR AND PANEL PARTS
Parts in DOOR AND PANEL PARTS
19 parts
| Ref | Image | Part / Description | Best Price |
|---|---|---|---|
| 1 | – | W10300759 Dishwasher Installation Manual | - |
| 1A | – | W10300682 Dishwasher Energy Guide | - |
| 1B | – | W10350367 Dishwasher Owner's Manual | - |
| 1C | – | W10350140 Technical Sheet | - |
| 1D | – | W10350141 Technical Sheet | - |
| 2 |  | W11612302replaces 8534854 Dishwasher Door Hinge | $77.34 PartSelect |
| 2A |  | W11612303replaces 8534853 Dishwasher Right Side Door Hinge Assembly | $60.05 Part Advantage |
| 3 |  | W10850371replaces W10321449 Barrier | $11.72 Part Advantage |
| 4 |  | W10350151NLA Dishwasher Door Outer Panel | Discontinued |
| 4A | – | W10350152 Dishwasher Door Panel | - |
| 4B | | Dishwasher Panel | - |
| 5 |  | W10827608replaces W10369038 Dishwasher Toe Panel | - |
| 5A |  | W10827630replaces W10369040 Dishwasher Access Panel | $100.15 RepairClinic |
| 6 |  | WPW10073520replaces W10073520 Dishwasher Outer Door Panel Insulation | $50.57 ApplianceParts Pro |
| 7 |  | W10831329replaces W10073540 Dishwasher Toe Panel Insulation | $15.72 Part Advantage |
| 8 |  | WPW10503548replaces W10331789 Retainer | $9.15 Part Advantage |
| 8A |  | WPW10503549replaces W10331793 Retainer | $2.22 Part Advantage |
| 9 |  | WP489069replaces 304392 Appliance Screw | $2.30 Part Advantage |
| 10 |  | WP3400071replaces 3400071 Dishwasher Control Panel Seal Screw | $2.30 Part Advantage |
